Taizhou Kayondの機械類Co.、株式会社
| Place of Origin: | Jiangsu, China |
|---|---|
| ブランド名: | KAD |
| Minimum Order Quantity: | 1 |
| 価格: | $1,376.19 |
| Fork Length: | 1220mm | Fork Width: | 125mm |
|---|---|---|---|
| Load Capacity: | 1500kg | Lifting Height: | 3000mm |
| Pedal Length: | 410mm | Driving Motor: | 0.75kw |
| Load Center: | 500mm | Axle Centre: | 700mm |
| Weight: | 610kg | Driving Wheel Size: | Φ160*55mm |
| Load Wheel Size: | Φ80*70mm | Balance Wheel Size: | Φ125*50mm |
| Max Lifting Height: | 2980mm | Overall Length: | 2000mm |
| Overall Width: | 855mm | ||
| ハイライト: | 1.5 ton electric pallet stacker,electric pallet stacker with 3m lift,warehouse electric pallet stacker |
||
| Attribute | Value |
|---|---|
| Model | CDDA15 |
| Applicable Industries | Building Material Shops |
| Condition | New |
| Load Capacity | 1500kg |
| Lifting Height | 3000mm |
| Power Source | DC MOTOR |
| Warranty | 1 Year |
| Drive Type | Electric |
| Fork Length | 1220mm |
| Fork Width | 125mm |
| Driving Motor | 0.75kw |
| Lifting Motor | 2.2kw |
| Battery Capacity | 48V/32Ah |
| Driving Speed (Empty/Full Load) | 4.5/5.5 km/h |
| Lifting Speed (Empty/Full Load) | 62/88 mm/s |
| Descending Speed (Empty/Full Load) | 94/70 mm/s |
| Max Gradient (Empty/Full Load) | 3°/5° |
| Noise Level | ≤70 dB(A) |
