Taizhou Kayondの機械類Co.、株式会社
| Place of Origin: | Jiangsu, China |
|---|---|
| ブランド名: | KAD |
| Minimum Order Quantity: | 1 |
| 価格: | $1,376.19 |
| Load Capacity: | 1500kg | Fork Length: | 1220-1520mm |
|---|---|---|---|
| Fork Width: | 160-180mm | Battery Capacity: | 24v/80Ah |
| Weight: | 600kg | Max Lifting Height: | 2980mm |
| Lowest Mast: | 2080mm | Overall Length: | 2000mm |
| Overall Width: | 855mm | Overall Height: | 2080mm |
| Driving Speed: | 4.5/5.5 km/h | Lifting Speed: | 62/88 mm/s |
| Descending Speed: | 94/70 mm/s | Driving Motor Power: | 0.8 KW |
| Lifting Motor Power: | 2.2 KW | ||
| ハイライト: | CE certified electric forklift truck,1.5 ton stand-on forklift,double lift pallet stacker |
||
The fully electric double-mast stacker is a cutting-edge logistics solution engineered to optimize warehouse efficiency. Its innovative dual lifting mechanism enables synchronized raising of the forks and platform, dramatically enhancing loading and stacking speed.
| Attribute | Value |
|---|---|
| Model | CDDA15 |
| Load Capacity | 1500kg |
| Max Lifting Height | 2980mm |
| Power Source | DC Motor (48V/32Ah Battery) |
| Drive Type | Electric |
| Tyre Type | Polyurethane |
| Warranty | 1 Year |
| Driving Speed (Empty/Full Load) | 4.5/5.5 km/h |
| Lifting Speed (Empty/Full Load) | 62/88 mm/s |
| Descending Speed (Empty/Full Load) | 94/70 mm/s |
| Min Turning Radius | 1730mm |
| Driving Motor Power | 0.8KW |
| Lifting Motor Power | 2.2KW |
| Noise Level | ≤70 dB(A) |
Control Handle: KAD brand domestic famous control handle with sensitive functional buttons for UP/DOWN, FORWARD/BACKWARD control.
Operation Panel: Features battery indicator, emergency switch, and functional controls with ergonomic design.
Mast Options: Available in 1-stage, 2-stage, or 3-stage configurations with reinforced steel construction.
A: Generally packed in paper package and iron pallet. Branded packaging available with authorization.
A: T/T 30% deposit, 70% before delivery with product photos provided.
A: Typically 5-30 days after deposit receipt, depending on order specifics.
