Taizhou Kayondの機械類Co.、株式会社
| 起源の場所: | 江蘇、中国 |
|---|---|
| ブランド名: | KAD |
| 最小注文数量: | 1 |
| 価格: | $1,285-1,680 |
| フォークの長さ: | 1070mm | フォークの幅: | 550/680mm |
|---|---|---|---|
| 負荷センター: | 500mm | 重量を積みます: | 1500kg |
| バッテリー電圧: | 24V | バッテリー容量: | 80Ah |
| 電池のタイプ: | 鉛酸 | ミン 持ち上げ高さ: | 2080mm |
| 全体的な寸法: | 1770x850x2080mm | 重さ: | 500kg |
| 速度の運転: | 5.0mm/s | 持ち上げ速度: | 140/135mm/秒 |
| 減速: | 150/155mm/秒 | 駆動モーター: | DC/0.75KW |
| リフティングモーター: | DC/2.2KW | ||
| ハイライト: | 1600kg electric pallet stacker,3000mm lift pallet stacker,KAD electric pallet stacker |
||
| Attribute | Value |
|---|---|
| Condition | New |
| Fork Length | 1070mm/customized |
| Fork Width | 550/680mm/customized |
| Applicable Industries | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Advertising |
| Terrain Adaptability | Indoor Flooring, Outdoor Pavement, other |
| Load Center | 500 mm |
| Load weight | 1500KG |
| Battery | 24V/80Ah |
| Battery type | Lead acid battery |
| Power Source | DC MOTOR |
| Warranty | 1 Year |
| Min. Lifting Height | 2080mm |
| Overall Dimensions | 1770(L)*850(w)*2080(h) |
| Weight (KG) | 500 kg |
| Model | CDDW10 | CDDW15 |
|---|---|---|
| Drive system | Battery | |
| Driving mode | Walkie | |
| Load Capacity (KG) | 1000 | 1500 |
| Load Center (MM) | 500 | |
| Lifting Height (MM) | 1600/2000 | 2500/3000 |
| Driving Speed (Empty/Full Load) (MM/S) | 5.0/5.0 | |
| Lifting Speed (Empty/Full Load) (MM/S) | 140/135 | |
| Battery Capacity (V/Ah) | 24/80Ah | |
Control Handle: Domestic famous control handle with functional buttons for UP/DOWN, FORWARD/BACKWARD control. Features Curtis brand accelerator for safe operation.
