Taizhou Kayondの機械類Co.、株式会社
| 最小注文数量: | 1 |
|---|---|
| 価格: | 2885 |
| モデル番号: | CDD1516 | 負荷容量: | 1〜1.5t |
|---|---|---|---|
| 負荷センター: | 500mm | リフトの高さ: | 1600mm |
| バッテリー容量: | 24v/210Ah | フォークの幅: | 850mm |
| 回転半径: | 1738/2099mm | フォークの長さ: | 1070mm |
| 総重量: | 1000.000kg | 駆動モーター: | 1.2kw |
| リフティングモーター: | 2.2kw | タイヤタイプ: | ポリウレタン |
| 速度の運転: | 4km/h | 全体的なサイズ: | 2170*1570*2100mm |
| 地上高: | 30mm | ||
| ハイライト: | 850mm Fork Width Electric Pallet Stacker,1738/2099mm Turning Radius Pallet Stacker,500mm Load Center Electric Forklift |
||
| Model | CDD1030 | CDD1530 |
|---|---|---|
| Load Capacity | 1000 kg | 1500 kg |
| Lifting Height | 3000 mm | 3000 mm |
| Load Center | 500 mm | 500 mm |
| Fork Size | 1220×100×40 mm | 1220×100×40 mm |
| Ground Clearance | 30 mm | 30 mm |
| Pedal Length | 410 mm | 410 mm |
| Handler Height | 1490 mm | 1490 mm |
| Outer Distance Between Forks | 685 mm | 685 mm |
| Inner Distance Between Forks | 345 mm | 345 mm |
| Tyre Type | Polyurethane | Polyurethane |
| Control Way | Handler | Handler |
| Speed Regulation Way | Stepless Speed Regulation | Stepless Speed Regulation |
| Min. Turning Radius | 1500 mm | 1500 mm |
| Driving Speed with Full Loads | 4 km/h | 4 km/h |
| Gradient | 3°/5° | 3°/5° |
| Battery | 24V/210A | 24V/210A |
| Driving Motor | 1.2 KW | 1.2 KW |
| Lifting Motor | 2.2 KW | 2.2 KW |
| Tyre Size | 300/250 mm | 300/250 mm |
| Overall Size | 2170×1570×2100 mm | 2170×1570×2100 mm |
| Weight | 900 kg | 900 kg |
| Reference Working Time | 6 h | 6 h |
| Increased Height Options | 1600/2000/2500/3000/3500 mm | 1600/2000/2500/3000/3500 mm |
| Max Height | 2100/1600/1850/2100/2350 mm | 2100/1600/1850/2100/2350 mm |
