Taizhou Kayondの機械類Co.、株式会社
| 起源の場所: | 江蘇、中国 |
|---|---|
| ブランド名: | KAD |
| 最小注文数量: | 1 |
| 価格: | $599-780 |
| フォークの長さ: | 1150mm、1220mm | フォークの幅: | 685、550 |
|---|---|---|---|
| 負荷容量: | 3トン | バッテリー電圧: | 48V |
| 回転半径: | 1200mm | 旅行速度: | 4km/h |
| 段階的な可能性: | 10％ | 駆動エンジンのパワー: | 1 kW |
| 持ち上がるモーター力: | 0.8 kW | 高さを持ち上げる: | 200 mm |
| 負荷センター: | 600 mm | バッテリー付きの重量: | 230kg |
| バッテリーの重量: | 36のKg | 充電時間: | 5-6時間 |
| 地上高: | 1200のmm | ||
| ハイライト: | 48V Battery Electric Pallet Truck,2 Years Warranty Powered Pallet Truck,Outdoor Electric Transpallet |
||
| Specification | Unit | Value |
|---|---|---|
| Drive Mode | Single motor dual wheel drive | |
| Rated Load | kg | 3000 |
| Operation Type | Walking | |
| Load Center | mm | 600 |
| Weight (with Battery) | kg | 230 |
| Voltage | V | 48 |
| Battery Weight | kg | 36 |
| Battery Specification | V/Ah | 4*12/32 |
| Charging Time (Full) | hour | 5-6 |
| Lifting Height | mm | 200 |
| Travel Speed (Loaded) | km/h | 3.5 |
| Travel Speed (Unloaded) | km/h | 4 |
| Driving Wheel | Solid Rubber Tire | |
| Fork Size | 80*70 (Polyurethane) | |
| Max Gradeability | % | 6/10 |
| Drive Control Type | Electric | |
| Steering Type | Manual | |
| Min. Ground Clearance | mm | 1200 |
| Min. Turning Radius | mm | 25 |
| Rated Power of Drive Motor | kW | 1 |
| Rated Power of Lifting Motor | kW | 0.8 |
| Fork Length | mm | 1150×160×55 |
| Overall Length (Forks 1150mm) | mm | 1690 |
| Overall Width | mm | 680 / 730 |
| Handle Height | mm | 1240 |
| Drive Wheel Size | mm | 250×100/300×100 |
